fits 2009-2023 5.7-liter, 2005-2010 6.1-liter and 2011-2023 6.4-liter Chrysler Gen III Hemi engines.
These new single-plane intake manifold kits are designed for 2009-Current 5.7-liter, 2005-2010 6.1-liter, and 20011-Current 6.4-liter Chrysler Gen III Hemi engines. They provide maximum hood clearance combined with plenum and runner geometry that provide a broad RPM powerband for high-performance street/strip engine applications to a maximum engine speed of 7500 RPM. The isolated design of the air/fuel passages helps to increase charge air density and performance.
These new single-plane intake manifold kits are designed for 2009-Current 5.7-liter, 2005-2010 6.1-liter, and 20011-Current 6.4-liter Chrysler Gen III Hemi engines. They provide maximum hood clearance combined with plenum and runner geometry that provide a broad RPM powerband for high-performance street/strip engine applications to a maximum engine speed of 7500 RPM. The isolated design of the air/fuel passages helps to increase charge air density and performance.
- O-ring seals around ports
- Cast aluminum construction. Great for turbocharger, centrifugal blower or NOS power adders
- 4150 type throttle/carb flange
- Designed for use with either Bosch EV1 or Gen III Hemi OEM fuel injectors
- Billet aluminum oil fill cap included
- Billet fuel rails included with 300-930, 300-930BK
- Height to throttle valve flange in front is 3.31-inch, rear is 4.25-inch
- Unique casting for 300-931, 300-931BK without injector bungs for clean appearance
- Minimum carb flange height for maximum clearance to hood
- Port size: 1.72-inches tall, 1.75-inches wide
Information:
These manifolds are designed to fit with 2009-Current 5.7L, 2005-2010 6.1L and 20011-Current 6.4L Chrysler Gen III Hemi engines. Adapter plates 300-652 will allow use with early, small port engines.| Attributes | |
| Basic Operating RPM Range | 2500-7500 |
| Brand | Holley, Holley |
| Carburetor Flange | 4150 Square Bore |
| Category | Engine, Engine |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| CNC Ported | No |
| Color | Black, Black |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Cylinder Head Port Shape | Square |
| Deck Height | 9.25 |
| EGR Port | No, No |
| Emission Code | 3, 3, Off Road |
| Engine | GEN 3 HEMI, GEN 3 HEMI |
| Finish | Black |
| Flange Style | 4150 Square Bore |
| Fuel Injectors Included | No, No |
| Gasket Or Seal Included | No, No |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum, Aluminum |
| Part Type | Engine Intake Manifold, Engine Intake Manifold |
| Plenum Finish | Black, Black |
| Product Type | Intake Manifold, Intake Manifold |
| RPM Power Band | 2500-7500 |
| SDR Required Flag | N |
| Single Or Dual Plane Type | Single Plane, Single Plane |
| Sub Category | Cylinder Block Components, Cylinder Block Components |
| Throttle Body Bore Diameter | 3.6 |
| Throttle Body Gasket Included | No |
| Vacuum Ports | 1 |
| Warning | California Proposition 65, California Proposition 65 |
| GTIN | 00090127296370 |
