Small Block Chevrolet - Gen III/IV - LSA
This kit looks truly at home on the LSA engine, so much so that nobody will realize it didn't come this way from the factory.
This kit looks truly at home on the LSA engine, so much so that nobody will realize it didn't come this way from the factory.
- Compatible with the original LSA damper/pulley and similar aftermarket versions
- OE pulley ratios for optimal accessory performance, allows for larger SC crank pulley
- Original Equipment look – Available in Natural and Black Finishes
- Compatible with LSA and 2010-15 LS Camaro water pumps
- All brackets, pulleys, and belts are supplied for both the supercharger and all accessories
- Notably more clearance for swap applications than other options
- Includes Holley compact SD7 A/C kit (P/N 20-160)
- Includes LT1 style premium 150-amp alternator
- Includes Holley’s Integral Reservoir and Type II Power Steering Pump and Bracket w/ baffled reservoir
- Power Steering Hard Line Adapter and P/S Pulley Also Included
Information:
Note: This drive works with the original LSA damper/pulley and similar aftermarket versions IMPORTANT NOTE IF PAINTING COMPONENTS: The alternator and A/C compressor ground through their mounting brackets. If painting or coating the brackets, the mating surfaces must all be bare metal allowing a ground path from the accessories' mounting feet to the engine block and ultimately the negative terminal on the battery. Helpful hint: When wiring the alternator, install the included 197-400 plug into the alternator. Next, connect the yellow wire to switched voltage that is "on" when the key is in the run position. If the vehicle has a "charge indicator light", the yellow wire can be connected to that circuit. The P/S pulley must be installed using an installation tool that can be rented at most auto parts stores. Incorrect installation of this pulley may damage the P/S pump internals. When installed, the pulley bore face should be flush with the end of the pump shaft. HELPFUL HINT: When installing the belt, route around all the pulleys except the water pump pulley. While fully rotating the tensioner arm, slip the belt on the smooth water pump pulley last. Use serpentine belt supplied if using ALL included Holley accessories and supplemental parts. NOTE: If you are NOT using all the Holley accessories supplied, or have changed the original crank or any accessory's pulleys, you will have to measure to find the correct belt length.| Attributes | |
| A/C Compressor Included | Yes |
| A/C Compressor Type | SD7 |
| Accessory Drive Style | Mid-Mount |
| Alternator Amperage | 150A |
| Alternator Included | Yes |
| Application | GM LSA |
| Belt Included | Yes |
| Brand | Holley |
| California Proposition 65 | No |
| Category | Accessory Drives, Engine |
| Category Filter | Accessory Drives |
| Clearance Category | Accessory Drives |
| Country of Origin (Primary) | CN |
| Damper Included | No, No |
| Damper Style | Factory, Factory |
| Emission Code | 5, 5 |
| Engine | GM LSA, GM LSA |
| Finish | Black, Black |
| Harmonized Tariff Code (Schedule B) | 8409910000 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Cast Aluminum, Cast Aluminum |
| NAFTA Preference Criterion Code | B |
| Part Type | Accessory Drive Belt Kit |
| Power Steering Hardline Included | Yes, Yes |
| Power Steering Pulley Included | Yes, Yes |
| Power Steering Pump Included | Yes, Yes |
| Power Steering Reservoir Included | Yes, Yes |
| Product Type | Accessory Bracket, Accessory Bracket |
| Pulley Style | Serpentine, Serpentine |
| Sale Category | Engine |
| SDR Required Flag | N |
| Sub Category | Accessory Drive Belt System Components |
| Tensioner Included | Yes, Yes |
| Thermostat Included | No, No |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Water Neck Included | No, No |
| Water Pump Included | No, No |
| Water Pump Pulley Included | No, No |
| GTIN | 00090127126356 |
