Fits 1998-2002 Camaro / Firebird - Single 450 LPH Pump Module
Part #: 12-364 - Twin 340LPH Pump Module
- Anodized and laser-etched billet 6061-T6 flange with 6AN ORB ports for feed, return, and vent
- Flanges have been designed to be compatible with feed and return line sizes up to -8AN
- Step-down butt connectors included to wire level sensor
- Can be connected to factory EVAP system (w/ use of 12-874 and 935056ERL - sold separately)
- Kit includes vehicle pigtail harness - All connectors used are DTM style
- All SKUs compatible with Gasoline AND E85
- Comes pre-installed with new pre-calibrated fuel level (33 – 240 Ω) and tank pressure sensors
- Includes new gasket to complete installation
- 3 x 11-inch HydraMat is included for each pump
- Fits factory plastic tank used in LS1 98-02 Camaro / Firebird or an earlier 4th Gen F-body with fuel tank upgrade
- Fittings included allowing connection to the factory 3/8 quick connect feed and return lines
Information:
Drive the vehicle until the level in the tank is at or below 1/8 of a tank. To make tank removal and reinstall as easy as possible, the lower the fuel level the better.
Application Summary:
| Year |
Make/Model |
| 1998-2002 |
Chevrolet Camaro |
| 1998-2002 |
Pontiac Firebird |
| Attributes |
| Average Current Draw |
16.9 |
| Average Flow Rating |
450 |
| Brand |
Holley, Holley |
| Category |
Air and Fuel Delivery |
| Connector Color |
Gray |
| Connector Gender |
Female |
| Connector Quantity |
1 |
| Country of Origin (Primary) |
US |
| Emission Code |
5, 5 |
| Finish |
Anodized Black, Anodized Black |
| Free Flow GPH |
118, 118 |
| Free Flow LPH |
450, 450 |
| Fuel Filter Included |
Yes |
| Fuel Sending Unit Included |
Yes |
| Fuel System |
EFI, EFI |
| Fuel Tank Pressure Sensor Included |
Yes |
| Fuel Type |
Gasoline/E85 Compatible, Gasoline/E85 Compatible |
| Gasket Or Seal Included |
Yes |
| Gasket Or Seal Material |
Rubber |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8409915085 |
| Hazardous Material Code |
N |
| Height |
Standard, Standard |
| Housing Material |
Aluminum |
| In Tank or External |
In Tank |
| Inlet Quantity |
One, One |
| Inlet Size |
6 AN ORB, 6 AN ORB |
| Inlet Type |
6 AN ORB |
| Internal Or External Strainer |
External |
| Life Cycle Status Code |
Available to Order |
| Lock Ring Included |
No |
| Material |
Billet Alluminum 6061-T6, Billet Alluminum 6061-T6 |
| Maximum Pressure |
60 |
| Mounting Hardware Included |
Yes |
| Negative Ground |
Yes |
| Outlet Quantity |
One, One |
| Outlet Size |
6 AN ORB, 6 AN ORB |
| Outlet Type |
6 AN ORB |
| Part Type |
Fuel Pump Module Assembly |
| Product Type |
Fuel Pump Module, Fuel Pump Module |
| Pump Type |
Electric |
| Regulator Included |
No |
| Resistance Ohms Empty |
33 |
| Resistance Ohms Full |
240 |
| SDR Required Flag |
N |
| Single or Dual Pump |
Single, Single |
| Sub Category |
Fuel Pumps and Related Components |
| Universal Or Specific Fit |
Specific |
| Voltage |
12 |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Wire Quantity |
4 |
| GTIN |
00090127142059 |
