This ACCEL GM HEI remote mount ignition coil is compatible with late model computer controlled remote mount HEI systems.
Engineered with optimized low resistance, high turns ratio windings around an M36 high silicone magnetic steel E-core for higher energy and voltage outputs. Results in quicker starts, improved idle quality, crisper throttle response and more high RPM power. Compatible with late model GM computer controlled remote mount HEI systems. Direct bolt-in, plug-in replacement. Can also work with CD ignition systems. Special high temperature epoxy resists shock and vibration, while increasing thermal conductivity. Brass coil wire contact increases energy transfer and resists corrosion better than aluminum. Comes complete with new mounting hardware. High dielectric strength ACCEL Yellow over molded housing. Output is 48,000 volts with 0.2 ohms resistance.
Engineered with optimized low resistance, high turns ratio windings around an M36 high silicone magnetic steel E-core for higher energy and voltage outputs. Results in quicker starts, improved idle quality, crisper throttle response and more high RPM power. Compatible with late model GM computer controlled remote mount HEI systems. Direct bolt-in, plug-in replacement. Can also work with CD ignition systems. Special high temperature epoxy resists shock and vibration, while increasing thermal conductivity. Brass coil wire contact increases energy transfer and resists corrosion better than aluminum. Comes complete with new mounting hardware. High dielectric strength ACCEL Yellow over molded housing. Output is 48,000 volts with 0.2 ohms resistance.
- Direct Plug In Replacement Direct OE Fit
- Advanced Bobbin Technology
- Highly Specialized Silicone Magnetic Steel Cores
- Standard Motor Products SMP Dr-49
- MSD 8231
Application Summary:
| Year | Make/Model |
|---|---|
| 1996 | Buick Commercial Chassis |
| 1996 | Buick Roadmaster |
| 1996 | Cadillac Commercial Chassis |
| 1999-2000 | Cadillac Escalade |
| 1996 | Cadillac Fleetwood |
| 1996-2005 | Chevrolet Astro |
| 1996 | Chevrolet Blazer |
| 1998-1999 | Chevrolet Blazer |
| 2001-2005 | Chevrolet Blazer |
| 1996-1999 | Chevrolet C1500 |
| 1996-2000 | Chevrolet C2500 |
| 1996-1998 | Chevrolet C2500 Suburban |
| 1991-2000 | Chevrolet C3500 |
| 1996-1997 | Chevrolet Camaro |
| 1996 | Chevrolet Caprice |
| 1996 | Chevrolet Corvette |
| 1996-2007 | Chevrolet Express 1500 |
| 1996-2005 | Chevrolet Express 2500 |
| 1996-2002 | Chevrolet Express 3500 |
| 1996 | Chevrolet Impala |
| 1996-1999 | Chevrolet K1500 |
| 1996-1999 | Chevrolet K1500 Suburban |
| 1996-2000 | Chevrolet K2500 |
| 1996-1999 | Chevrolet K2500 Suburban |
| 1996-2000 | Chevrolet K3500 |
| 1997-1999 | Chevrolet P30 |
| 1996-2004 | Chevrolet S10 |
| 1999-2006 | Chevrolet Silverado 1500 |
| 2007 | Chevrolet Silverado 1500 Classic |
| 2001 | Chevrolet Silverado 3500 |
| 2003-2006 | Chevrolet Silverado 3500 |
| 1996-1999 | Chevrolet Suburban 1500 |
| 1996-2000 | Chevrolet Tahoe |
| 1996-1999 | GMC C1500 |
| 1996-1999 | GMC C1500 Suburban |
| 1996-2000 | GMC C2500 |
| 1996-1999 | GMC C2500 Suburban |
| 1991-2000 | GMC C3500 |
| 1996-2001 | GMC Jimmy |
| 1996-1999 | GMC K1500 |
| 1996-1999 | GMC K1500 Suburban |
| 1996-2000 | GMC K2500 |
| 1996-2000 | GMC K3500 |
| 1996-2001 | GMC Safari |
| 2003-2004 | GMC Safari |
| 1996-2007 | GMC Savana 1500 |
| 1996-2005 | GMC Savana 2500 |
| 1996-2002 | GMC Savana 3500 |
| 1999-2006 | GMC Sierra 1500 |
| 2002-2006 | GMC Sierra 3500 |
| 1996-2004 | GMC Sonoma |
| 1996-2000 | GMC Yukon |
| 2000 | Isuzu Hombre |
| 1996-2001 | Oldsmobile Bravada |
| 1996-1997 | Pontiac Firebird |
| Attributes | |
| ASIN | B000VU1H0Q |
| Application | GM, GM |
| Brand | ACCEL |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition Coils |
| Color | Yellow, Yellow |
| Country of Origin (Primary) | US |
| Emission Code | 2, 2 |
| GTIN | 00743047801840 |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 48000, 48,000 volts |
| NAFTA Preference Criterion Code | B |
| Package Quantity | 1 |
| Part Type | Ignition Coil |
| Peak Increase in Energy | 11% |
| Peak Increase in Energy vs. OE | 11%, 11% |
| Primary Resistance | .200 ohms, 0.2 Ohms |
| Product Type | Ignition Coils, Ignition Coils |
| Quantity | 1, 1 |
| Quantity Per Pkg. | 1, 1 |
| SDR Required Flag | N |
| Sale Category | Ignition |
| Secondary Resistance | 6.7K ohms, 6.7 k Ohms |
| Sub Category | Ignition Coil, Ignition Coil |
| Turns Ratio | 92:1, 92:1 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day Warranty, Manufacturer's Limited 90 Day Warranty |
| Warranty Time | 90 |
| Weight | 1.2, 1.2000 |
ACCEL 140024ACC ACCEL Ignition Coil - SuperCoil - GM Vortec engine 1996-2001 5.0/5.7/7.4L
Product Information
- Brand: ACCEL
- Product Number: 140024ACC
- Availability: Call for Availability
